If you are having disc read errors this guide may be of assistance. If your discs seem to be loading fine (mechanically) but do not read it's likely your laser is bad.

Thanks to: TIGUY99 for producing the guide!

PS3 Disc Read Error Repair Guide

This fix is for those of you that don't seem to have problems running downloaded games and using media off of sources that are not the drive. Most often this is caused by the Blu-Ray laser going bad.

This will require a part KES-400AAA looks like the going rate is $70-$100.

Some Additional Tips Not In The Guide:

• If you have worked on PCs this shouldn't be that hard. If you have worked on Notebooks, you shouldn't find the PS3 to be very difficult at all. Most notebook chassis are far more tedious then the PS3's.
• DOWNLOAD THE TIGUY99 GUIDE!!!! Read the guide a couple of times. Note the manner in which the PS3 is sitting in each photo.
• Have the guide open on your notebook or PC as you work. Otherwise print it out.
• Make sure you have enough time to take it apart and put it back together. It will take about an hour. You don't want to take it apart then try to put it back together the next morning.
• Make sure you have a clean work area. With PLENTY OF LIGHT, I used my kitchen counter.
• Have places to sit parts out of the way.
• Have the right tools, you don't want to strip every screw.
• Get a ground strap in addition to the tools outlined.
• Have several containers to keep the screws in, one for each level of "disassembly" is what I used.
• Careful getting the first rubber foot off, I trashed mine.
• Keep track of where the coarse threaded vs. fine threaded screws come from. The coarse threaded screws generally screw directly into the plastic chassis.
• Clean the pieces as you disassemble the PS3, a vacuum with a hose attachment and canned air work great. Stubborn dust bunnies may require a paper towel dampened with alcohol.
• Keep the work area clean as you work. Be careful not to vacuum any screws. This will insure no dust (or pet hair) get into any of the blu-ray drive's internal areas.
• A few minor steps are missing from the guide, but they are fairly easy to figure out.
• Careful with the ribbon cables, each one has a clip to hold them on. Some release the opposite way of others.
• Righty tighty, lefty loosey!
• When assembling the PS3 make sure you have all the cables where they should be as you put it together. You don't want to have to take it back apart a bit to get a cable where it's supposed to be. Be sure ports meet the port-holes as they are supposed to. Over all everything should have a tight fit.
• When you put the screws back in you just need to secure everything, you aren't entering a strongman contest. Over torquing these screws may result in a funny looking PS3.

DOWNLOAD: blue ray lasor replace by TIGUY99.pdf

[gilksy]

cool
nice write up!
tiguy99 will be happy

[tiguy99]

Originally Posted by gilksy

cool
nice write up!
tiguy99 will be happy

Thanks I'm glad the guide is there to help those in need.

[D.Vader]

Originally Posted by tiguy99

Thanks I'm glad the guide is there to help those in need.

Another PS3 Surgeon! Welcome!

[kidd_76]

I've decided to fix myself and need to know which laser my ps3 has. I've looked every where to no avail. Any help would be much appreciated. And thank you, TIGUY99 for the guide to repair it.

[jimbo76]

very useful guide, many thanks.

I have a ps3 that will load the game but will not read discs so it has got to be the laser like you say.... I hope so anyway

[ZemaOner]

Ze doctors!!! Thanks guys!

[mc752]

Thank you so much for this guide. My laser was fine, but the gears in the Blu-Ray Drive (the ones that feed the disc in/out and spin it) somehow broke, but I had a working laser. So I bought a Blu-Ray Drive off of ebay with a broken laser and, with this guide, replaced lasers.

[ZemaOner]

On a scale of 1-10, how hard/tedious was it to take apart the Blu-ray drive?

[Dehshizknight]

Originally Posted by mc752

Thank you so much for this guide. My laser was fine, but the gears in the Blu-Ray Drive (the ones that feed the disc in/out and spin it) somehow broke, but I had a working laser. So I bought a Blu-Ray Drive off of ebay with a broken laser and, with this guide, replaced lasers.

Just out of curiosity, is your PS3 usually vertical or horizontal?
